Sicar 315mm (12") 1.6m 5.5HP Sliding Italian Designed Panel Saw 415V SEGA315 SE
The SEGA 315 SE shares the same high-precision sliding table saw specs as the SEGA 300 series (315 mm blade diameter, 4,000 rpm blade speed, independent scoring motor, ~1250 mm rip capacity).
However, the SEGA 315 SE takes durability and rigidity up a notch:
Heavier machine body and cast-iron support structure — Built around reinforced main frames with round-bar guides and micrometric adjustment, designed for long-term workshop stability and minimal vibration.
Larger sliding table and oversized carriage dimensions — The standard sliding beam for the SEGA 315 is listed as 3200 × 375 mm.
Higher net/gross machine weight
Specifications
- Main Blade Diameter: Φ(250~315)xΦ30
- Main Blade Speed: 4000 RPM
- Scoring Blade Diameter: Φ120xΦ20
- Scoring Blade Speed 8000mm
- Max Depth of Cut @ 45 ° : 75mm
- Max Depth of Cut @ 90 ° : 100mm
- Max Rip Capacity 1250mm
- Main Table Size: 910x550mm
- Main extend Table Size: 910x760mm
- Side extend Table Size: 500x550mm
- Dust Extraction Outlet: 100mm
- Overhead blade guard with 100mm dust port
- Main Blade Motor Output 5.5HP
- Scoring Blade Motor Output 0.75KW 1HP
- CE Style Overhead Guard Included
Technical - Main
Motor Power (Output) 5HP (3.73kW)
Power Source 415V 50Hz Three Phase
Blade - Electric Rise / Fall No
Cut Max. Depth @ 90° 100mm
Cut Max. Depth @ 45° 75mm
Rip Capacity 1250mm
Electrical Connection
Excludes Plug & Lead (must be connected by Licensed Electrician)
Technical - Saw
Sliding Table (Cross Cut) Size 1600mm
Blade (Main) - Bore Size (mm) 30mm
Blade (Main) - Diameter (Max.) 300mm
Blade (Main) - Speed 4000RPM
Blade (Scoring) - Diameter (Max.) 120mm
Blade (Scoring) - Speed 8000RPM
Blade Tilt 0-45°
Dimensions
Product Weight (Net Weight) 610kg
Workshop (Site) Info
Dust Hose Inlet Diameter 1 x 120mm
12 months Manufacturer's Warranty
This machine does not qualify for FREE Freight and requires a saw technician to assemble calibrate on site.
