Lock Mortiser FC116U by Virutex, Manufactured in Spain


Specially designed for quick, precise mortising on doors or other elements, either at the work site or in the workshop. Its special fixing system allows the mortising of doors that have already been hung, without damaging the surface. Its quick measurement adjustment permits multiple mortises to be made in record time. Also able to work horizontally. For mortising grooved doors or those with overlap, there is an adjustment system to centre the machine.


Optional bits are low-cost and easily inter-changeable, which keeps the preparation of the FC116U to a minimum when mortising fittings for lock fronts. It comes factory-equipped with tool UT16I, which allows for making quick, precise transverse holes for inserting handles and other parts.



  • Double insulation
  • Input power: 1100W
  • Max. bit Ø: 30mm
  • Max. mortising depth: 0 - 125mm
  • Max. mortising length: 177mm +
  • Max. clamp vise opening: 190mm
  • No-load speed: 23.000/min


Standard Accessories:-

  • Carbide Lock Mortiser Bit Ø 16 mm
  • Locking bar to make mortises on several doors at the same height
  • Rubber Protectors for delicate jobs
  • UT16I
  • Service Keys
  • Dust Collector connection


Optional accessories:-

  • Carbide Bits suit Lock Mortiser
  • Clamp Extension UP16I
  • Drilling Accessory UT16I
  • Carbide Drilling Bit* 2 c. Ø 18 mm
  • Carbide Drilling Bit* 2 c. Ø 23 mm


Full 12 Month Manufacturer’s Warranty

VIRUTEX Lock Mortiser FC116U

SKU: 8600394
